| Part Number | MCDLT31NF |
| Product | Servo Driver |
| Details | A6NF series RTEX Ultra high-speed Network type (Multi type) with the safety function |
| Product name | MINAS A6N Series Servo Driver |
| Features | Realtime Express (RTEX) Advanced Network to realize high-precise real-time performance for Servo Control |
| Item | Specifications |
|---|---|
| Part Number | MCDLT31NF |
| Details | A6NF series RTEX Ultra high-speed Network type (Multi type) with the safety function |
| Family Name | MINAS A6 |
| Series | A6NF series |
| Type | RTEX, Ultra high-speed Network type (Multi type) |
| Frame | C-Frame |
| Frequency response (kHz) | 3.2 |
| Control method | Position control, Velocity control, Torque control, and Full-closed control |
| Safety Function | with |
| Supply voltage | Single phase 100 V |
| I/F Classification of type | RTEX |
| Dimensions (W) (Unit: mm) | 65 |
| Dimensions (H) (Unit: mm) | 150 |
| Dimensions (D) (Unit: mm) | 170 |
| Mass (kg) | 1.6 |
| Environment | For more details, please refer to the instruction manual. |
| Qty | Unit Price | Sale Price |
