      Embedded IPC PCX-9702-16GB+MSATA-512GB

      $559.00 $0 View Details
      Model: PCX-9702-16GB+MSATA-512GB SKU: 10000144970701 Category: Embedded IPC Brand: KERNAL Condition: New Sealed Under Guarantee Size: 219.00 mm, 145.00 mm, 65.00 mm Weight: 1.67kg Product Selection Engineer: Lixintao Order No: PCX-9702-16GB+MSATA-512GB Shipping:
      Leading
      Warehouse

      1. Intel Celeron N5105 CPU

      2. DDR4-2133~3200MHz SODIMM memory design, up to 16GB

      3. 1 x mSATA + 1 x M.2 interface

      4. 1*VGA, maximum resolution up to 1920*1200@60 Hz

      5. 3*Intel I225-AT 10/100/1000M network ports, two of which support PoE

      6. 3*USB3.0,1*USB2.0

      7. 2 x RS-232 (1 by default), 1 x RS-485

      8. DC 24V power supply, with anti-reverse connection and overcurrent protection

      PCX-9702 Specifications
      System
      Hardware      		ProcessorModelKernelFrequencyHighest turbo FrequencyMaximum MemoryCachePower Consumption
      Celeron
      N5105      		4C4T2.0GHZ2.9GHZ16GB4MB10W
      Memory260-Pin DDR4-2133~3200MHz SO-DIMM single-channel memory, up to 16GB
      Operating systemWin10 64-bit 21H2 and above with Ubuntu 20.04
      GraphicsDisplay INTEL UHD Graphics
      BIOSAMI BIOS
      Watch DogsSupport 256 levels (0~255), programmable
      Power SupplyPower supplyDC IN 24V, standard product comes with 24V/4A power adapter
      Startup modePower-on auto-power/key-triggered power-on (the default power-on auto-boot, key-triggered power-on mode can be set by hardware/BIOS).
      Power switch1*With light switch
      Panel
      Interface      		Display mode1*VGA: The maximum resolution is 1920*1200@ 60 Hz
      COM1/2The default is 1*3-wire RS-232, using 1 standard DB-9 block (2*3-wire RS-232 can be customized.) , you need to buy our wiring to use).
      COM31*RS-485, green phoenix terminal
      RemoteSW1*Remote switch, green phoenix terminal
      PWR1*Power indicator, green phoenix terminal
      LAN1*Gigabit Ethernet port, using Intel I225 chip, support Wake-on-LAN,
      Speed: 10/100/1000Mbps/(2.5Gbps optional).
      PoE2*PoE, using Inteli225 chip, support Wake-on-LAN, speed: 10/100/1000Mbps
      USB3*USB3.0,1*USB2.0
      Built
      interface      		 M .21*M.2 hard disk interface (M.2 2280 SATA).
      SW31*Clock reset
      MSATA1*miniPCIe slot, support mSATA (capacity 64/128/256/480/512GB optional).
      J_AT11*Power on mode setting
      USB2*Single-layer heightened USB2.0, can be connected to dongle
      ReliabilityOperating temperature-20°C~70°C (excluding electronic disk).
      Storage temperature-40°C~85°C (excluding electronic disk).
      Relative humidity5%~90% non-condensing (excluding electronic disks).
      Vibration while workingSystem installation SSD/mSATA: 3 Grms, IEC 60068-2-64 random 5 ~ 500 Hz
      Shock while workingSystem installation SSD/mSATA: 30 G, IEC 60068-2-27
      StructureInstallation:Horizontal mounting/rail mounting/wall mounting
      Horizontal sizeBracket included: 219*145*65mm(L*W*H)
      Din rail mountingBracket included: 189*154.28*65mm(L*W*H)
      Wall-mountedBracket included: 229*147*65mm(L*W*H)
      The weight of the whole machineApprox. 1.67Kg (excluding accessories and packaging).
      CertificationRelevant certificatesROHS，CE ，FCC
